Designed for versatility, the Stellar 100 is a noninvasive ventilator with invasive capabilities. Offering a comprehensive range of therapy modes, Stellar treats a wide range of adult and paediatric patient types with changing respiratory needs. From those who need NIV during their hospital stay to chronic patients at home with conditions, such as COPD, NMD and OHS, Stellar is a versatile system designed with its end-users in mind.

Steller 100 v1.5 Asia Pac

SKU: 24164
  • Key features

      Stellar 100
    Modes ST (Spontaneous–Timed)

    PAC (Pressure Assisted Control)

    CPAP (Continuous Positive Airway Pressure)

    S (Spontaneous)

    T (Timed)
    Pressure range IPAP: 2–40 cm H2O

    EPAP: 2–25 cm H2O
    TiControl™ Ti Max 0.3–4 sec

    Ti Min 0.1–Ti Max
    Respiratory Rate 5–60 bpm
    Rise Time Min, 150–900 msec (approx.)
    Trigger and Cycle Five sensitivity settings
    Adjustable alarms High Leak

    Low Minute Ventilation

    Low and High Pressure

    Low and High Respiratory Rate


    Low and High FiO2

    Low SpO2

    Non-vented mask
    Standard fixed alarms Circuit disconnected

    Over pressure

    Blocked tube

    Internal battery empty
    Dimensions (LxWxH) 230 x 170 x 120 mm
    Weight 2.1 kg
    Air filter Electrostatic fibre mesh
    Air outlet 22 mm taper, compatible with ISO5356–1:2004
    Internal battery Lithium-ion, 2 hours at EPAP 5, IPAP 15, 20 bpm
    Power supply AC 100–240V 50–60Hz,

    2.2A AC 110V 400Hz,

    2.2A DC 24V/3A
    IEC 60601–1 Classification Class II (double insulation) Type BF Continuous operation
    Data solutions ResScan

    EasyCare Tx software and Tx Link
